Main Features:

  1. 3D graphics with 24” LCD monitor
  2. During counterweight fitting, fully automatic cycle with pneumatic braking to ease locking/unlocking of the wheel.
  3. Selection of TRUCK / CAR modes
  4. Multi-functional keyboard, user friendly.
  5. Automatic distance and diameter measurement
  6. Auto Start works with lowering the wheel guard.
  7. Wheel positioning automatically according to the unbalance position on external side.
  8. Self-diagnosis, self-calibration programs.
  9. ALU/ALU-S/ALU-S1 programs for aluminum wheels – AUTOMATIC.
  10. For dividing the counterweights behind spokes of alloy rims, there is SPLIT (Hidden Weight) program
  11. Optimization program for compensating the tire and rim for optimum balancing.
Technical Features
Accuracy 1gr. Car / 10gr Truck.
Measuring time 8 – 20 sec.
Max.wheel weight 250 kg.
Max. Wheel diameter 1300 mm.
Wheel diameter 10” – 30”
Wheel width 1,5”-20”
Power supply 115/230 V., 50/60 Hz.
Balancing speed 150 rpm Car / 80 rpm Truck.
Air Pressure 8-10 bar
