Weight from 0,1 – 75 Kg Horizontal Balancing Machine

These balancing machines are kardan or belt driven balancing machines according to the rotor types and suitable for balancing operations at horizontal axis for rotors between 0,1 – 75 kg. The balance correction can be adjusted as additional / removal method. Optionally, horizontal or vertical axis working manual drilling unit can be mounted on the system. With the user-friendly software, the operation is very easy.

  • Computerized
  • Innovative design
  • High balancing accuracy

OPTIONAL ACCESSORIES

  • Additional bench
  • Special protection cage
  • Horizontal drilling unit
  • Vertical drilling unit
  • Spot welding unit

Photos

SYM-1075-TEKAN-TEKNİK-(5)
SYM-1075-TEKAN-TEKNİK-(4)
SYM-1075-TEKAN-TEKNİK-(3)
SYM-1075-TEKAN-TEKNİK-(2)
SYM-1075-TEKAN-TEKNİK-(1)
SYM-1075-(3)
SYM-1075-(2)
SYM-1075-(1)
SYM-1000-(4)
SYM-1000-(3)
SYM-1000-(2)
SYM-1000-(1)
IMG-20150803-WA0025
20150805_104049
4338
4331
_MG_9308
_MG_9288
_MG_9262
_MG_9244
_MG_9236

Technical Information

Technicial Specifications / Unit

SYM 1000

SYM 1030

SYM 1075

Maximum Weight

0,1 – 10

0,2 – 30

1 – 75

Maximum Rotor Diameter

300

300

400

Bearing Diameter

5 - 30

10 - 50

10 - 50

Balancing RPM

6000

6000

6000

Standard Bench Length

500

500

1000

MaximumRotorLength

300

300

600

MotorPower                                                                (kW)

0,37

0,55

1,1
